Next, bend the wire into a pig tail loop so that you can easily attach to the screws on the light switch. The wire strippers should have a spot marked for each gauge wire. Then, use your wire strippers and strip away about 5/8 of an inch of the insulation from the wire.
Stripping the Wiresįirst, know what gauge wire you are working with. You will want to replicate that same wiring scheme when you install the new switch. If there are more wires for a three-way switch, then also keep track of where those were also connected. See where the black and white wires are connected. Important – If you are replacing an existing switch, make sure that you take not of how it is wired before you remove the existing wires. Red Wire – This wire is used for 3 or 4 way switches and will connect the switches together so they can each control your lights.Bare Copper (Green) Wire – This is your ground wire.Black Wire – This is the hot or load wire.
#Cooper light switch wiring diagram how to#
Tools Needed to Wire a Light Switchīasic Knowledge of How to Wire a Light Switch If you do not know which breaker feeds your switch, then just turn on the light and test each breaker until you find the one that turns off your lights. It is important to also read the directions that come with your particular light switch because there may be something different about the one you purchased or a change in technology that would require a different light switch installation.īefore you do anything, you will need to cut the power to the light switch. Our instructions on how to wire a light switch for a standard light switch, a three-way light switch and a four-way light switch are outlined below. As a homeowner, you will likely need to replace a light switch many times and paying an electrician is not optimal when you can do it in just a few minutes. Learning how to wire a light switch is one of the basic skills that every homeowner should do.
